Exposure XM5 Integrated Amplifier

Exposure XM5 Integrated Amplifier

1,260.00

The Exposure XM5 integrated amplifier is part of Exposure's recently introduced XM series of compact half width components. It combines a 60 watts per channel integrated amplifier, a DAC with asynchronous USB and DSD support, and a moving magnet phono stage.

Call ‭0161 917 0642, email info@strictlystereo.com or contact us with a question about this product.

Price Match | Free Delivery | Free 30 Day Returns

Options:
Quantity:
Add To Cart

Product Details

  • Large 200VA custom-made toroidal power transformer
  • High quality all aluminium casework and extruded front panel
  • High quality resistors & capacitors used in the signal path
  • Cascode circuitry utilised for improved power supply immunity
  • Toshiba bipolar output transistors for dynamics and performance
  • 60 watts per channel into 8 Ohms
  • Moving magnet phono input, fixed level AV input and one line level input
  • Two coax ( bnc) and two optical inputs and one class 2 USB input with DSD
  • Separate pre-amp output
  • Remote control
  • Three year guarantee
  • Available in black or titanium

Specifications

Speaker Output Specifications

  • Power Output (1KHz) : 60 Watts per channel into 8 ohms
  • Total Harmonic Distortion : <0.01% at 1KHz, rated power
  • Frequency Response : 20Hz - 20KHz +/- 0.5dB
  • Channel Separation : >60dB @ 1KHz AUX 2 input open (shorted > 80dB) >40dB @ 20KHz AUX 2 input open (shorted > 63dB)

Pre Amplifier Specifications

  • Pre Amplifier Output : Gain +12dB
  • Frequency Response : 20Hz - 20KHz +/- 0.5dB
  • Total Harmonic Distortion : @ 1KHz: & 1V ouput : 0.002%
  • Signal to Noise Ratio ref 1KHz & 1V ouput : >100dB, A weighted
  • Channel Separation @ 20KHz : >62dB input shorted > 41dB input open AUX 2 input

Input Specifications

  • AV input fixed level : 450mV @ 1KHz > 12K ohms S/N > 100dB
  • AUX/PH input MM : 2.5mV @ 1KHz, 47K ohms S/N 70dB
  • AUX 2 input Line : 350mV @ 1KHz > 14K ohms S/N > 100dB
  • SPDIF inputs BNC Coax & Optical : 32 - 192KHz @ 16-24 bits
  • USB input : Linear PCM 44K1 - 192KHz @ 16-24 bits DSD x64 (DoP) Asynchronous transfer from host

General Specifications

  • Mains Supply : 110/120V or 220/240V @ 50/60Hz (factory set)
  • Power Consumption : 200W both channels driven, 8 ohms load
  • Dimensions (WxHxD) : 218mm x 89mm x 363mm (inc knob)
  • Net Weight (unpacked) : 5kg
  • Gross Weight (packed) : 6kg
